A PRACTICAL WORKFLOW ACROSS INDUSTRIES

Step-by-Step Project Execution
for Mechanical Engineering Services

From customer enquiry to concept, detailed 3D CAD, virtual validation, manufacturing documentation, and final handover — a disciplined, repeatable pathway for zero shop-floor surprises.

Signed NDA & Scoping Lock
9 Formal Stage-Gate Signoffs
One Source of CAD Truth
Right-Sized CAE Validation

Overall Project Lifecycle & Core Principles

This guide provides a repeatable baseline process for MTERQUBEE SOLUTIONS. Apply the same project controls across industries, then tailor technical tasks, standards, and approval gates to the product and customer.

MTERQUBEE END-TO-END PROJECT EXECUTION LIFECYCLE OVERVIEW
MTERQUBEE Step-by-Step Project Execution Lifecycle Overview
CONTROL PRINCIPLE WHAT IT MEANS IN PRACTICE
One Source of Truth Store approved requirements, 3D CAD models, 2D drawings, BOMs, and review records in strictly controlled vault locations.
Stage-Gate Approvals Obtain customer sign-off at requirements, concept feasibility, detailed design review, and final release stages.
Traceability Connect each important engineering requirement to a specific CAD design feature and an agreed verification method.
Change Control Assess and approve all changes to scope, geometry, schedule, and deliverables before engineering implementation.
Right-Sized Validation Select hand calculations, finite element simulation (FEA), or physical testing according to risk, intended use, and agreed scope.
01Enquiry
02Discovery
03Scope
04Concept
053D CAD
06Validation
072D Prints
08Release
09Handover

The 9 Project Execution Stages

Each stage includes explicit action items, client discovery questions, stage-gate signoff records, and workflow verification diagrams.

STAGE 01 GATE 01 APPROVAL ISO 9001:2015 §8.2
// SCOPING & RISK LOCK
// STAGE 01

Enquiry & Qualification

GATE 01

Understand the customer, application, and business need.

// CORE ACTIONS
  • Acknowledge the enquiry and identify customer, industry, application, and decision-maker.
  • Clarify the business problem, current situation, expected benefits, and project urgency.
  • Request available sketches, drawings, photos, sample parts, specifications, and legacy CAD.
  • Identify target completion dates, preferred CAD platform, deliverable formats, and project size.
  • Check technical capability fit, confidentiality requirements, mutual NDA, and potential conflicts.
// QUESTIONS TO ASK CLIENT
  • What product, machine, or system needs engineering support?
  • What exact technical problem are you trying to solve?
  • What reference inputs, drawings, or sketches are available?
  • What file formats do you expect and by what deadline?
  • Who will review and approve the engineering output?
Gate Record: Enquiry record and initial project brief. Proceed when the opportunity and next info-gathering step are clear.
STAGE 01 WORKFLOW BLUEPRINT • ISO 9001:2015 §8.2
Stage 01: Enquiry & Qualification Workflow Blueprint
STAGE 02 GATE 02 APPROVAL ISO 9001:2015 §8.2.2
// REQUIREMENTS BASELINE
// STAGE 02

Discovery & Requirements

GATE 02

Turn the customer request into clear, testable engineering requirements.

// CORE ACTIONS
  • Arrange a formal discovery meeting with technical and commercial stakeholders.
  • Document functional requirements, performance, load cases, duty cycles, operating environment, and constraints.
  • Identify materials, surface finishes, manufacturing methods, maintenance needs, and customer standards.
  • Separate mandatory engineering requirements from optional preferences and working assumptions.
  • Create an input register showing document names, revisions, owners, and status; log missing info.
// USEFUL PROJECT RECORDS
Requirements Register Interface List Input Document Register Assumptions Log Initial Risk Register
Gate Record: Customer confirms requirements baseline or explicitly accepts unresolved assumptions before concept selection.
STAGE 02 WORKFLOW BLUEPRINT • ISO 9001:2015 §8.2.2
Stage 02: Discovery & Requirements Workflow Blueprint
STAGE 03 GATE 03 APPROVAL ISO 9001:2015 §8.2.3
// SOW & WBS LOCK
// STAGE 03

Scope, Proposal & Planning

GATE 03

Agree what will be delivered, when, and by whom.

// CORE ACTIONS
  • Write a clear Scope of Work (SOW) with explicit inclusions, exclusions, and boundaries.
  • List deliverables and formats: native CAD, neutral STEP, 2D drawings, BOM, analysis reports, renders, or manuals.
  • Define the exact number of concept iterations and review/revision cycles included.
  • Break work into WBS tasks, assign owners, and estimate engineering effort and dependencies.
  • Set milestones, communication cadence, design review gates, and formal acceptance criteria.
  • Establish change-control rules: any later scope change is documented and approved before execution.
// GATE 03 CLOSURE CHECKLIST
  • Are all required technical inputs and boundaries documented?
  • Are engineering responsibilities and approval owners clear?
  • Are commercial payment milestones and sprint schedules agreed?
  • Is the proposal approved with mutual NDA active?
Gate Record: Approved quotation/proposal and project plan. Any later scope change is documented and approved.
STAGE 03 WORKFLOW BLUEPRINT • ISO 9001:2015 §8.2.3
Stage 03: Scope, Proposal & Planning Workflow Blueprint
STAGE 04 GATE 04 APPROVAL ISO 9001:2015 §8.3.2
// DFMA TRADE-OFF MATRIX
// STAGE 04

Concept & Feasibility

GATE 04

Compare options before committing capital to detailed 3D design.

// CORE ACTIONS
  • Generate concept sketches, block diagrams, preliminary layouts, or low-detail 3D CAD models.
  • Compare options against requirements, cost, manufacturability, assembly, service access, and schedule.
  • Check key interfaces, packaging envelopes, weight targets, and major buyout components.
  • Identify major engineering risks and what calculations, simulations, or tests are required.
  • Present alternatives with clear trade-offs; record the selected concept and client feedback.
// KEY EVALUATION CRITERIA
DFMA Manufacturability Space Envelope Fit Target BOM Cost Operator Ergonomics Safety & Compliance
Gate Record: Approved concept, design basis, key architectural decisions, updated risk list, and agreed next-stage inputs.
STAGE 04 WORKFLOW BLUEPRINT • ISO 9001:2015 §8.3.2
Stage 04: Concept & Feasibility Workflow Blueprint
STAGE 05 GATE 05 APPROVAL ASME Y14.41 / ISO 16792
// 3D PARAMETRIC VAULT
// STAGE 05

Detailed 3D CAD Design

GATE 05

Build a coordinated, manufacturing-aware digital model.

// CORE ACTIONS
  • Create structured, parametric 3D CAD models with clear naming and revision conventions.
  • Build parts and assemblies around agreed interfaces, dimensions, and parent-child design intent.
  • Select materials, standard components, fasteners, and manufacturing processes within scope.
  • Check dynamic fit, clearances, assembly sequence, serviceability, and maintenance access.
  • Apply appropriate tolerance strategy and identify critical datum features for shop drawings.
  • Maintain a decision log and update drawings/models whenever client requirements change.
// CAD INTEGRITY CHECKS
  • Zero unintended solid interference clashes.
  • Complete standard fastener hardware populated.
  • Tool clearance for wrenches, ratchets, and drivers.
  • Clean feature trees with no broken sketch references.
Gate Record: Preliminary or detailed design review with model screenshots, open issues, and a clear list of items requiring customer decision.
STAGE 05 WORKFLOW BLUEPRINT • ASME Y14.41 / ISO 16792
Stage 05: Detailed 3D CAD Design Workflow Blueprint
STAGE 06 GATE 06 APPROVAL ASME V&V 10 / CAE
// FEA & INTERFERENCE AUDIT
// STAGE 06

Verification & Validation

GATE 06

Check the engineering design against requirements and intended use.

// CORE ACTIONS
  • Map requirements to inspection, engineering calculation, simulation, or testing methods.
  • Conduct peer checks and interference/clearance audits across all operating positions.
  • Complete calculations for relevant loads, mechanisms, drives, structures, or thermal/fluid behavior.
  • Use CAE/CFD only with documented material data, loads, boundary conditions, and limitations.
  • Review results with a competent engineer; verify mesh convergence and numerical sensitivity.
  • Track findings, corrective actions, residual risks, and any need for physical validation.
// VALIDATION MATRIX
Every critical constraint (Stress, Deflection, Torque, Thermal dissipation, Flow rate) is cross-referenced with a formal verification method and acceptable factor of safety.
Gate Record: Verification matrix, calculation/analysis report if scoped, design review record, and action closure. (Simulation is not a substitute for required physical certification).
STAGE 06 WORKFLOW BLUEPRINT • ASME V&V 10 / CAE
Stage 06: Verification & Validation Workflow Blueprint
STAGE 07 GATE 07 APPROVAL ASME Y14.5M / ISO 1101
// 2D PRINTS & BOM RELEASE
// STAGE 07

Manufacturing Documentation

GATE 07

Create clear, coordinated information for shop-floor production.

// CORE ACTIONS
  • Generate 2D part, assembly, fabrication, and weldment drawings to agreed standards (ASME/ISO).
  • Specify dimensions, tolerances, materials, finishes, weld symbols, hardware, and title notes clearly.
  • Generate a BOM with item numbers, quantities, material specs, and approved vendor part numbers.
  • Prepare exploded views, assembly instructions, manuals, and spare-parts information if included.
  • Check that drawings, BOM, and released 3D models agree 100%; verify units and revision levels.
// DRAWING PACKAGE ASSETS
Vector PDF Prints Laser Cut Flat DXFs ASME Y14.5M GD&T Weld Cut Lists Structured Excel BOM
Gate Record: Manufacturing documentation checklist and coordinated drawing/BOM package ready for formal client review.
STAGE 07 WORKFLOW BLUEPRINT • ASME Y14.5M / ISO 1101
Stage 07: Manufacturing Documentation Workflow Blueprint
STAGE 08 GATE 08 APPROVAL ISO 9001:2015 §8.5.6
// ECN & PRODUCTION AUDIT
// STAGE 08

Review, Release & Support

GATE 08

Control approvals and help resolve agreed production queries.

// CORE ACTIONS
  • Conduct a formal review against requirements, design rules, and agreed acceptance criteria.
  • Log each review comment with an owner, due date, technical response, and closure status.
  • Obtain required customer sign-off and internal engineering quality approvals.
  • Release files with a formal transmittal listing filenames, revisions, status, and release dates.
  • Respond to manufacturing queries within agreed scope and log all approved deviations.
  • Assess any change for impact on requirements, safety, analysis, drawings, cost, and schedule.
// RELEASE AUDIT CRITERIA
  • All markup comments closed and verified.
  • Title blocks show correct revision letter (Rev A).
  • ECN deviation register updated.
  • Sign-off transmittal record signed by lead PE.
Gate Record: Approved release package, review log, change/deviation log, and transmittal record.
STAGE 08 WORKFLOW BLUEPRINT • ISO 9001:2015 §8.5.6
Stage 08: Review, Release & Support Workflow Blueprint
STAGE 09 GATE 09 COMPLETE ISO 9001:2015 §10.2
// IP TRANSFER & LESSONS LEARNED
// STAGE 09

Handover & Continuous Improvement

GATE 09 COMPLETE

Transfer the final engineering package and learn from delivery.

// CORE ACTIONS
  • Deliver final files using the agreed secure transfer method and organized folder structure.
  • Include a document index, revision history, known limitations, and open handover items.
  • Conduct a technical handover walkthrough meeting with client engineering staff.
  • Confirm receipt and customer acceptance according to the contract terms.
  • Archive working files and approvals under company data retention and security rules.
  • Capture lessons learned and compare actual performance metrics with planned baselines.
// CLOSURE & ARCHIVE
Deliverables are archived under encrypted storage with SHA-256 integrity checksums and 100% intellectual property transfer to the client.
Gate Record: Handover pack, formal acceptance/closure record, and internal lessons-learned summary.
STAGE 09 WORKFLOW BLUEPRINT • ISO 9001:2015 §10.2
Stage 09: Handover & Continuous Improvement Workflow Blueprint

Final Project Verification Checklist

Before any project is marked closed, our project management team verifies every area against this comprehensive checklist.

CONTROL AREA CHECK BEFORE CLOSING
Scope All agreed deliverables complete; formal exclusions and open items clearly documented.
Technical Requirements verified; required calculations, interference checks, analyses, or tests formally recorded.
Documentation 3D Models, 2D drawings, BOMs, and manuals consistent; units, datums, and revisions checked.
Approval Review comments closed or formally accepted; customer milestone approvals captured in writing.
Delivery Files transferred securely via encrypted vault; transmittal record and document index included.
Commercial Approved change requests logged and agreed commercial closeout terms completed.
Improvement Lessons learned and relevant project turnaround metrics recorded without speculative claims.

Tailoring the Workflow by Industry

We keep the project management framework consistent across all engagements, while tailoring the technical requirements to the specific industry vertical:

  • Conveyor Projects: Emphasize throughput, drive interfaces, guarding, and maintenance access.
  • Automotive Work: Emphasize GD&T datum schemes, tight packaging, and cyclic fatigue validation.
  • Food Processing: Emphasize sanitary washdown, drainage radii, crevice-free welds, and food-grade materials.
  • Drone & Aerospace: Require specialist airworthiness, CG weight budgets, and vibration analysis.
Client-Facing Summary: MTERQUBEE SOLUTIONS follows a structured engineering workflow — from enquiry and requirements definition through concept development, detailed CAD, verification, manufacturing documentation, controlled release, and handover.
INDUSTRY-SPECIFIC ADAPTATION MATRIX
Adaptation by Industry Process Diagram
